OLE-HW2000 Handheld Laser Welding Machine
Handheld laser welding with single-axis wobbling feature; Laser power 2KW.
- Features
- Technical Data
Compact integrated design with easy operation.
Wobble welding to improve welding capacity to seam.
Wire feeder as optional to expand application range.
Multiple safety protection with auto beam off function once the nozzle goes away from workpiece.
Various welding nozzles included for option.
|
Model |
OLE-HW2000 |
Cooling |
Water Cooling |
|
|
Laser |
Maxphotonics/Raycus |
Cover Glass |
Φ18mm*2mm |
|
|
Laser Power |
2000W |
Collimation Length |
60mm |
|
|
Laser Wavelength |
1080nm |
Focus Length |
150mm |
|
|
Fiber Length |
10m |
Power Supply |
380V/3-Phase/50 or 60Hz |
|
|
Fiber Core |
50um |
Overall Dimension |
1053x800x1225mm (LxWxH) |
|
|
Welding Speed |
0-120mm/s |
|
Weight |
~280kg |
|
Welding Style |
Wobble (single axis) |
|
Wire Feeder |
Included |
|
Wobbling Range |
0-5mm (Line) |
|
Wire Diameter |
Max. 2.0mm
|
|
Welding Seam Width |
5mm |
|
Wire Weight |
Max. 25kg |
|
Melting Depth |
Max. 4.5mm (SS), 4mm (MS), 1.8mm (AL) based on 1500W laser |
|
Wire Material |
Copper/SS/AL |
|
|
|
|
|
|
