OLE-HW1000 Handheld Laser Welding Machine

Handheld laser welding with single-axis wobbling feature; Laser power 1KW.

  • Features
  • Technical Data


Compact integrated design with easy operation.
Wobble welding to improve welding capacity to seam.
Wire feeder as optional to expand application range.
Multiple safety protection with auto beam off function once the nozzle goes away from workpiece.
Various welding nozzles included for option.

Model

OLE-HW1000

Cooling

Water Cooling

Laser

Maxphotonics/Raycus

Cover Glass

Φ18mm*2mm

Laser Power

1000W

Collimation Length

60mm

Laser Wavelength

1080nm

Focus Length

150mm

Fiber Length

10m

Power Supply

220V/Single Phase/50 or 60Hz;

Fiber Core

50um

Overall Dimension

1053x800x1225mm (LxWxH)

Welding Speed

0-120mm/s



Weight

~235kg

Welding Style

Wobble (single axis)



Wire Feeder

Included

Wobbling Range

0-5mm (Line)



Wire Diameter

Max. 2.0mm

Welding Seam Width

5mm



Wire Weight

Max. 25kg

Melting Depth

Max. 4.5mm (SS), 4mm (MS), 1.8mm (AL) based on 1500W laser



Wire Material

Copper/SS/AL
